Detailed user guide for JVC GZ‑MS110 and GZ‑MS118 camcorders covering setup, recording, playback, troubleshooting and specifications.
This manual provides step‑by‑step instructions for getting started with the JVC GZ‑MS110 and GZ‑MS118 camcorders, including charging the battery, inserting SD cards, and configuring basic settings such as clock and language. It also explains how to mount the camera on a tripod, use it abroad, and select accessories for travel.
The guide covers all operating modes—automatic and manual recording, zoom, focus, exposure, white‑balance, and back‑light compensation—as well as playback functions, file management, and video transfer to a PC or DVD recorder. Troubleshooting tips, maintenance procedures, and a full specification table are included at the end of the document. This manual is written in Chinese.
| Dimensions (W×H×D) | 52 × 62 × 110 mm |
|---|---|
| Camera weight (without battery) | ≈195 g |
| Camera weight (with battery) | ≈220 g |
| Power consumption (monitor backlight standard) | 1.5 W |
| Battery voltage | 3.6 V |
| Battery capacity | 700 mAh |
| Optical zoom | up to 39× |
| Digital zoom | up to 800× |
| LCD monitor size | 2.7 inches |
Connect the AC adapter (model AP‑V30M) to the camcorder; the adapter supplies 5.2 V DC for charging the battery.
The camcorder supports SDHC cards; see the section "可以使用的 SD卡类型" for details.
Select "确定" on the prompt "要进行格式化吗？" and choose to format the SD card, which will delete all data and allow new recordings.
