The JVC GY-LS300CHU/GY-LS300CHE user manual provides setup, safety, operation and technical specifications for the 4K memory‑card camera recorder.
This manual covers safety precautions, installation steps, and detailed operating instructions for the JVC GY‑LS300CHU/GY‑LS300CHE 4K memory‑card camera recorder. It includes guidance on attaching the handle unit, lens, microphone, tripod, and battery pack, as well as wiring and terminal connections for AC power, HDMI, SDI and audio.
The document also describes the device’s specifications such as power requirements, dimensions, supported media, sensor type, and LCD monitor features, and provides troubleshooting and maintenance information for safe and reliable use.
| Power Input | DC 12 V |
|---|---|
| Power Consumption (4K mode) | ≈ 9.8 W |
| Mass (with battery) | ≈ 1.7 kg |
| Operating Temperature | 0 °C to 40 °C |
| Dimensions (W × H × D) | 135 mm × 191 mm × 359 mm |
| Supported Media | SDHC/SDXC slots × 2 |
| Image Sensor | Super 35 mm Progressive CMOS |
| LCD Monitor | 3.5‑inch, 920 K pixels, 16:9 |
| HDMI Output | Type‑A, HDMI 1.4‑compliant |
| SDI OUT | 3G‑SDI (BNC) compliant with SMPTE ST424 |
The unit uses a lithium‑ion battery pack; replacement batteries must be CR2025 cells from Panasonic, Sanyo, Sony or Maxell, and must not be recharged, disassembled, heated above 100 °C, or incinerated.
Do not open the unit or remove the cover; there are no user‑serviceable parts inside and all servicing must be performed by qualified personnel.
The recorder can be powered by a DC 12 V supply (≈ 9.8 W in 4K mode) or by an AC adapter with automatic voltage selection from 110 V to 240 V.
The camera provides two SDHC/SDXC slots, allowing two cards to be used at the same time.
