The Holtek HT48R062/HT48C062 is an economical 8‑bit microcontroller with 11 bidirectional I/O pins, built‑in crystal/RC oscillator, watchdog timer, 1 KB ROM…
The HT48R062/HT48C062 series is a low‑cost 8‑bit MCU designed for economical multi‑I/O control in industrial, consumer and subsystem applications. It offers stable I/O, low power consumption, built‑in oscillator options and a watchdog timer.
Key functional blocks include a 14‑bit program memory (1 K words), 8‑bit data memory (32 bytes), an arithmetic‑logic unit (ALU), status registers, a programmable oscillator (crystal or RC), and a watchdog timer with configurable prescaler. The device is supplied in 16‑pin DIP or NSOP packages. This manual is written in Chinese.
| Maximum operating frequency | 8 MHz |
|---|---|
| Program memory size | 1 K × 14 bits |
| Data memory size | 32 × 8 bits |
| I/O pins | 11 bidirectional I/O pins |
| Power consumption (typical, 5 V, 8 MHz) | ≈500 mW |
| Oscillator options | Built‑in crystal or RC oscillator |
The MCU provides 11 bidirectional I/O pins.
It has 1 K words of 14‑bit program memory (ROM).
