This document describes the features and characteristics of the 24V VFD Eight-bit HT48R065V OTP microcontroller produced by Holtek Semiconductor Inc. It includes information on the operating voltage range, system frequency, oscillation modes, operating modes, memory capacity, instruction system, hardware stack, and input/output ports of the product.
The HT48R065V is a 24 V VFD‑type 8‑bit high‑performance MCU with low power consumption, multiple I/O functions, timers, and built‑in oscillators. It is offered in a compact 52‑pin QFP package and is suitable for a variety of control applications.
The document provides detailed pin descriptions, electrical parameters, oscillator options, and package dimensions, together with test conditions for both DC and AC characteristics. This manual is written in Japanese.
| Package | 52‑pin QFP‑A |
|---|---|
| Sleep mode current | ≈10 nA |
It is supplied in a 52‑pin QFP‑A package.
Sleep mode current consumption is about 10 nA.
