Hantek Hantek6022BL Oscilloscope User Manual

The Hantek Hantek6022BL Oscilloscope User Manual provides safety guidelines, system requirements, installation steps, and operation instructions.

Brand: Hantek
Category: Other Electronics
Document type: User Manual
Language: English
Pages: 61
File format: PDF
File size: 1.4 MB
Published: 28 September, 2026
Updated: 28 September, 2026
MD5 checksum: 19213F73834EF6B5E45A41B514A75AC9
PDF: Hantek Hantek6022BL Oscilloscope User Manual PDF

About this manual

This manual covers safety precautions, system requirements, software and driver installation, and basic features of the Hantek6022BL handheld oscilloscope. It guides users through basic operation, menu navigation, vertical and horizontal settings, trigger configuration, and input connections.

Additional sections describe advanced functions such as measurement tools, X‑Y mode, cursor measurements, and the built‑in logic analyzer, followed by application examples, specifications, and maintenance information.

What's inside

General Safety Overview
System Requirements
Software Installation
Driver Installation
Basic Features
Probe Compensation
Self‑Calibration
User Interface
Vertical System
Horizontal System

Specifications

Analog Channels	2
Analog Bandwidth	20MHz(-3dB)
Input Impedance	1MΩ
Resolution	8 bits
Maximum Real‑time Sampling Rate	48MSa/s
Timebase Range	1ns/div to 5000s/div
Trigger Sources	CH1, CH2
Logic Analyzer Bandwidth	10MHz

Frequently asked questions

How is the Hantek6022BL powered?

The device does not require an external power supply; it is powered directly from the USB connection.

How many analog channels does the oscilloscope have?

The oscilloscope provides two analog input channels.

What is the maximum real‑time sampling rate of the instrument?

The maximum real‑time sampling rate is 48 MSa/s.

Download PDF (1.4 MB)
