The Hantek DSO1000 series handheld oscilloscope user manual provides safety guidelines, operation instructions, specifications, and maintenance information.
The DSO1000 series handheld oscilloscope from Hantek offers dual‑channel measurement with bandwidths up to 600 MHz, sampling rates up to 2 GSa/s, a color TFT display and USB storage, making it suitable for engineering, field work, education and research. The device includes advanced trigger modes, FFT, automatic measurements and a built‑in multimeter function.
The manual is organized into safety overview, introductory sections, detailed operating instructions, application examples, a digital multimeter chapter, troubleshooting, technical specifications and appendices that list accessories, warranty information and cleaning/maintenance procedures. This manual is written in Chinese.
| Bandwidth | 60 MHz (DSO1060), 200 MHz (DSO1200), 600 MHz (DSO1600/1600H) |
|---|---|
| Maximum Real‑time Sampling Rate | 150 MSa/s (DSO1060), 500 MSa/s (DSO1200), 1 GSa/s (DSO1600), 2 GSa/s (DSO1600H) |
| Memory Length | 32 K points (single channel), 16 K points per channel (dual channel) |
| Display | Color TFT LCD, 320 × 240 pixels |
| External Interface | USB 2.0, optional RS‑232 and LAN |
| Power Supply | AC 100‑240 V, 50‑60 Hz; DC 8.5 V DC, 1.5 A |
| Battery Runtime | Approximately 6 hours on a full charge |
| Dimensions | 245 × 163 × 52 mm |
| Weight | 1.2 kg |
The built‑in lithium battery provides about six hours of operation on a full charge.
The package includes two 1.2 m passive probes (1:1, 10:1), a power cable with adapter, the user manual, a registration form, a warranty card, and a PC communication software CD.
DSO1060 has 60 MHz, DSO1200 has 200 MHz, and both DSO1600 and DSO1600H have 600 MHz bandwidth.
