Gigabyte Z690M AORUS ELITE AX DDR4 Motherboard User Manual

This manual provides installation instructions, hardware setup, BIOS configuration, and specifications for the Gigabyte Z690M AORUS ELITE AX DDR4 motherboard.

Brand: Gigabyte
Category: Motherboard
Document type: User Manual
Language: Chinese
Pages: 44
File format: PDF
File size: 24 MB
Published: 17 October, 2026
Updated: 17 October, 2026
MD5 checksum: BF1AFD6F345097E0A30E8D158F3CED75
PDF: Gigabyte Z690M AORUS ELITE AX DDR4 Motherboard User Manual PDF

About this manual

This user manual covers the Gigabyte Z690M AORUS ELITE AX DDR4 motherboard, including product features, hardware installation steps, and BIOS settings. It guides users through clearing the CMOS, installing the CPU and cooling fan, and configuring the system for optimal performance. This manual is written in Chinese.

What's inside

Product Features
Hardware Installation
CPU Installation
Memory Installation
BIOS Settings
Operating System Installation
Appendix
Regulatory Notices
Warranty Information
Global Service Network

Specifications

CPU Socket	LGA1700
Chipset	Intel® Z690
Memory Support	DDR4 3200/3000/2933/2666/2400/2133 MHz
Max Memory Capacity	128 GB
Network	Intel® 2.5GbE
Wireless	Intel® Wi-Fi 6 AX201
Form Factor	Micro ATX

Frequently asked questions

What is the maximum memory capacity supported?

The motherboard supports up to 128 GB of memory.

Which CPU socket does this motherboard use?

It uses the LGA1700 socket.

Does this model include a wireless module?

Yes, it includes an Intel® Wi-Fi 6 AX201 module.
