This Fuji Electric price list provides specifications and unit prices for the ACB DW, BW Global Twin, and BX series molded case circuit breakers.
The document is a price list for Fuji Electric's low‑voltage circuit breaker portfolio. It includes technical data, optional accessories, and unit prices for each product variant. Prices are shown in Thai Baht and are subject to change without notice.
The list covers three main series – ACB DW, BW Global Twin, and BX – with a range of frame sizes, interrupting capacities and pole configurations. Detailed tables give rated current, breaking capacity, and available accessories such as auxiliary switches, alarm switches, and external CT modules.
| Interrupting capacity (ACB DW) | 65 kA at Icu 400 V |
|---|---|
| Current rating range (ACB DW) | 1000 AF to 6300 AF |
| Frame size codes (ACB DW) | 08: 800 AF, 10: 1000 AF, 12: 1250 AF |
| Trip unit type (ACB DW) | Micrologic 2.0 (Standard protection) |
| Standard accessories (ACB DW) | 4 Auxiliary switch (4 c/o), Alarm switch (ADE) |
The ACB DW series provides an interrupting capacity of 65 kA at Icu 400 V.
Optional accessories include a 4‑pole auxiliary switch, alarm switch, door frame, padlocking device, and external CT modules.
Frame sizes range from 08 (800 AF) to 12 (1250 AF) and larger, e.g., 10 (1000 AF).
