Technical specifications and features of the FUJI AM22VME emergency stop pushbutton switch with mechanical indicator.
The FUJI AM22VME emergency stop pushbutton switch provides a mechanical indicator that shows the operating status in green or red. It includes safety features such as a push‑lock action that prevents accidental activation and a direct‑opening NC contact for reliable circuit breaking.
The switch is rated for indoor use with IP65 protection, UL, CSA, CE and TÜV certifications, and offers various contact arrangements (1NC, 1NO+1NC, 2NC, etc.) to suit different control panel designs.
| Rated insulation voltage (Ui) | 600 V AC/DC |
|---|---|
| Mechanical durability | 300,000 operations or more |
| Insulation resistance | 100 MΩ or more |
| Operating ambient temperature | -20 °C to +60 °C |
| Degree of protection (operator section) | IP65 |
| Conditional short‑circuit current | 1000 A |
| Maximum required operating force (average) | 22 N |
The average maximum operating force is 22 N.
The operator section is protected to IP65 (dust‑proof and water‑jet proof).
Up to four contacts are available, with arrangements such as 1NC, 1NO+1NC, 2NC, 1NO+2NC, 3NC, 1NO+3NC, 2NO+2NC, and 4NO.
