The manual provides safety instructions, operation guidelines, and specifications for the Fluke 5320A multi‑function calibrator.
This manual covers safety information, proper handling, and general description of the Fluke 5320A multi‑function calibrator, which integrates high‑voltage, low‑frequency, and high‑resistance sources for electrical safety testing.
Key functions include a 5 kV high‑voltage source, up to 10 TΩ resistance source, and automatic calibration via MET/CAL® Plus software. The document also lists performance specifications, certification marks, and maintenance procedures. This manual is written in Chinese.
| Maximum High Voltage Output | 5 kV |
|---|---|
| Maximum Resistance Output | 10 TΩ |
| Resistance Measurement Range | 100.25 MΩ |
| Peak Voltage | 1575 Vpk |
| Voltage (RMS) | 1000 V rms |
Automatic calibration is performed with MET/CAL® Plus software.
