EMC DWTR 8K Programmer User Manual

The EMC DWTR 8K programmer manual explains how to connect, configure, load program files and program Renesas 8‑bit microcontrollers.

Brand: EMC
Category: Other Electronics
Document type: User Manual
Language: Chinese
Pages: 9
File format: PDF
File size: 470 KB
Updated: 28 September, 2026
MD5 checksum: 11127F2022F401093EBABEAAB9B7A45F
PDF: EMC DWTR 8K Programmer User Manual PDF

About this manual

This manual provides step‑by‑step instructions for using the EMC DWTR 8K programming device. It covers power‑up, connection of the programmer, selection of the target microcontroller and loading of program files.

Key sections include power‑supply requirements, supported device families, file format details (CDS), option settings, and the actual programming procedure with troubleshooting tips. This manual is written in Chinese.

What's inside

Introduction
Power Supply Requirements
Supported Microcontroller Families
Connecting the Programmer
File Formats and Loading
Programming Procedure
Option and Setting Configuration
Troubleshooting

Specifications

Power Supply	18 V adapter
Firmware Version	EMB8P132
Print Part	378H

Frequently asked questions

What power supply is required for the DWTR 8K programmer?

The device must be powered with an 18 V adapter.

Which file format is used to load programs into the DWTR 8K?

Program files are loaded in the .cds format.

How do I select the correct microcontroller model for programming?

Choose the appropriate model (e.g., EM78P1S6N) from the device list before starting the programming operation.
