The E-Lins H700 Series is an industrial-grade 3G/4G dual SIM router designed for IoT and M2M applications. It utilizes a high-performance 32-bit dual-core processor and supports a wide range of network bands for 2G, 3G, and 4G connectivity. The device is built with a metal enclosure (IP30 protection) and features a robust power input range of DC 5~40V. This manual is written in Chinese.
| Processor | Industrial grade 32-bit dual-core communication processor |
|---|---|
| Flash Memory | 16MB (expandable to 1024 MB/8Gb) |
| RAM | 256MB (expandable to 512MB/4Gb) |
| Power Input | DC 5~40V (optional DC 5~60V) |
| Ethernet LAN | 1 x 10/100/1000 M RJ45 |
| Ethernet WAN | 4 x 10/100/1000 M RJ45 |
| SIM Card Slots | 2 x SIM/UIM |
| WiFi Standard | 802.11b/g/n |
| Protection Level | IP30 |
The standard power input is DC 5~40V, with an optional range of DC 5~60V.
The router supports a wide power input range of DC 5~40V, with an optional range of DC 5~60V.
The theoretical speeds are 300Mbps for downlink and 50Mbps for uplink.
The supported serial port rates include 300bps, 600bps, 1200bps, 2400bps, 4800bps, 9600bps, 19200bps, 38400bps, 57600bps, 115200bps.
