This datasheet describes the E-Lins H720tp industrial IoT router, featuring dual SIM slots for 2G/3G/4G networks, dual-link failover, and rich interfaces…
The E-Lins H720tp is an industrial-grade wireless communication router designed for IoT applications. It utilizes a dual-module, dual-SIM architecture to support simultaneous or backup connections across different public networks, including 2G, 3G, and 4G LTE. The device features a high-performance 32-bit communication processor and an embedded Linux operating system to ensure stable data transmission in harsh environments. This manual is written in Chinese.
| Processor | Industrial grade 32-bit communication processor |
|---|---|
| Operating System | Linux |
| Flash Memory | 8MB (expandable to 64MB/512Mb) |
| RAM | 64MB (expandable to 128MB/1024Mb) |
| Ethernet LAN Ports | 4 x 10/100M RJ45 |
| Ethernet WAN Port | 1 x 10/100M RJ45 |
| Serial Port | 1 x RS232 (or RS485) |
| Power Input | DC 5~40V (optional DC 5~50V) |
| Idle Current | Approx. 170mA @ 12VDC |
| Communication Current | Approx. 320mA @ 12VDC |
| LTE Downlink Speed | 100Mbps, 150Mbps, or 300Mbps |
| LTE Uplink Speed | 50Mbps |
| WIFI Standard | 802.11b/g/n 300Mbps |
| VPN Encryption Speed | 5M~200M bps |
It supports 2G GSM/GPRS/EDGE, 3G WCDMA HSDPA/HSUPA, and 4G FDD LTE or TD-LTE networks.
It allows free switching between different operators to ensure system stability, with options for single SIM or dual SIM backup modes.
The device features a metal housing with a protection level of IP30.
Yes, the standard configuration includes 4 LAN ports and 1 WAN port that support POE functionality.
