This manual covers the operation concepts, software usage, program editing steps, and troubleshooting for Delta Electronics AH Motion Controllers.
This document serves as an operation guide for the Delta Electronics AH Motion Controller series. It introduces fundamental motion control concepts, provides a brief overview of the ISPSoft programming software, details the steps for editing motion control programs, and includes information on system troubleshooting.
The manual is designed to be used in conjunction with other related documentation, such as the Hardware Manual, ISPSoft User Manual, Standard Instruction Manual, Motion Control Instruction Manual, and AH500 Module Manuals. It covers specifications, installation, software configuration, hardware setup, and fault diagnosis for models including AH08EMC-5A, AH10EMC-5A, AH20EMC-5A, and the AH500 series modules. This manual is written in Chinese.
| Operating Temperature | -20~60°C |
|---|---|
| Storage Temperature | -40~70°C |
| Operating Humidity | 5~95%, no condensation |
| Programming Languages | Ladder Diagram, CFC, ST, SFC |
| Program Capacity | 256K steps |
| Installation Method | DIN rail or screw mounting |
This manual applies to the AHxxEMC-5A series (AH08EMC-5A, AH10EMC-5A, AH20EMC-5A) and AH500 series modules.
The program executes in a cyclic scanning manner.
