This manual provides installation, operation, control function, parameter settings, communication protocols, and maintenance instructions for the Delta…
The document is a comprehensive application technology manual for the Delta Electronics ASDA-B2 series standard universal servo drives. It covers essential topics including product inspection, model identification, installation environments, wiring configurations (power, motor, encoder, I/O), and panel operation procedures.
Key sections guide users through trial rotation steps, tuning processes, and troubleshooting common alarms. The manual also details communication protocols such as RS-485/RS-232 and MODBUS, along with specific technical specifications for both the servo drives and compatible ECMA series servo motors. This manual is written in Chinese.
| Drive Type | Open Type Servo Drive |
|---|---|
| Control Processor | Digital Signal Processor (DSP) |
| Motor Type Supported | Three-phase Permanent Magnet Synchronous AC Servo Motor |
The manual is suitable for servo system designers, installation or wiring personnel, trial rotation and tuning staff, and maintenance or inspection personnel.
Connecting three-phase power to the motor output terminals will damage the servo drive.
