CITILED CLL801-0101A7-65CM1A2 Data Sheet

The CITILED CLL801-0101A7-65CM1A2 data sheet provides specifications, performance, reliability and handling guidelines for this LED chip.

Brand: CITILED
Category: Other Electronics
Document type: Datasheet
Language: English
Pages: 14
File format: PDF
File size: 609 KB
Published: 29 September, 2026
Updated: 29 September, 2026
MD5 checksum: 247F5EA7B01BCA8020AD07F3719963C4
PDF: CITILED CLL801-0101A7-65CM1A2 Data Sheet PDF

About this manual

This data sheet describes the CLL801-0101A7-65CM1A2 LED chip, including its electrical and optical characteristics such as forward voltage, luminous flux, CRI and correlated color temperature. It also lists the chip's dimensions, maximum ratings and recommended circuit design practices.

Additional sections cover reliability testing, tape and reel packaging, moisture‑proof packing, soldering and washing procedures, eye‑safety considerations, and general precautions for product use and design.

What's inside

Scope of Application
Outline Dimensions
Performance Ratings
Electro‑optical Characteristics
Reliability Tests
Taping Specifications
Packing Specifications
Soldering Precautions
Eye Safety
Designing Precautions

Specifications

Correlated Color Temperature	6500 K
Color Rendering Index (CRI)	Ra ≥ 80
Operating Temperature Range	-30 °C to +85 °C

Frequently asked questions

What is the recommended soldering paste for this LED chip?

A lead‑free solder paste composed of Sn 3.5 Ag 0.75 Cu with a melting temperature of 216 ~ 220 °C is recommended.

How should the LED chips be stored to prevent moisture?

Store the reels in a dry box or desiccator at 5 ~ 30 °C with humidity not exceeding 60 % RH.

What is the correlated color temperature of this LED chip?

The LED emits light with a correlated color temperature of 6500 K.
