The TITAN-F 800 is a mobile stainless‑steel vacuum machine with Z 3000 sensor control, high‑pressure sealing and IP65 protection.
The TITAN‑F 800 vacuum machine is a mobile, ready‑to‑use unit built from stainless steel for easy cleaning and hygienic operation. It features a Z 3000 sensor control with 99 programme memories, high‑pressure sealing bars and optional transparent panels for process monitoring.
Technical data include internal dimensions of 845 × 600 × 210 mm, a vacuum pump capacity of 63 m³/h or 100 m³/h, and IP65‑rated electrical parts. Optional equipment such as gas‑flush devices, extra‑high lids and adjustable sealing systems allow customization for various packaging requirements.
| Internal dimensions | 845 x 600 x 210 mm |
|---|---|
| Sealing bar length | 480 / 550 / 810 mm |
| Vacuum pump flow | 63 m³/h or 100 m³/h |
| Weight | 252 kg or 270 kg |
| Electrical connection | 3 phases, 230 V / 400 V, 50 Hz (special voltages on request) |
| IP rating of electrical parts | IP65 |
| Programme memories (Z 3000 control) | 99 |
The Z 3000 sensor control provides 99 programme memories.
The electrical components are protected to IP65.
The machine can be equipped with a vacuum pump delivering either 63 m³/h or 100 m³/h.
The internal dimensions are 845 mm × 600 mm × 210 mm.
