The ATEN KL1116 LCD KVM switcher user manual provides installation, setup, operation, and maintenance instructions.
This manual covers all aspects of the ATEN KL1116 LCD KVM switcher, including safety guidelines, rack‑mount installation, wiring, and detailed OSD configuration. It also explains the hot‑key functions, firmware upgrade process, and provides troubleshooting tips.
The document includes a full specification table, packaging contents, warranty information, and contact details for ALTUSEN authorized dealers. Users can follow the step‑by‑step procedures to connect up to 16 computers directly and expand up to 512 ports via daisy‑chain. This manual is written in Chinese.
| Directly connectable computers | 16 |
|---|---|
| Maximum ports via daisy‑chain | 512 |
| LCD size (15") | 1024 x 768 |
| Power consumption | 24W (120V 60Hz / 230V 50Hz) |
| Operating temperature | 0 – 50 °C |
| Storage temperature | -20 – 60 °C |
| Dimensions (L×W×H) | 68 × 44.8 × 4.2 cm |
The manual advises not to place the unit on an unstable surface, keep it away from liquids, ensure proper ventilation, and follow all warning symbols on the device.
The KL1116 can be directly connected to up to 16 computers.
Up to 512 ports can be reached by daisy‑chaining multiple units.
The device operates between 0 °C and 50 °C.
