The Allied Telesis x510 Series offers stackable Gigabit Layer 3 switches with advanced security, resiliency, PoE+, and flexible management features.
The x510 Series provides a range of stackable Gigabit Layer 3 switches designed for enterprise networks. Models include 24‑ and 48‑port variants with 1/10 Gbps uplinks, dual power supplies, and support for Virtual Chassis Stacking (VCStack) and Ethernet Protection Switched Ring (EPSRing) for high availability.
Key capabilities include the Allied Telesis Management Framework (AMF) for centralized configuration, PoE+ up to 30 W per port, extensive QoS, ACLs, and IPv6 support. The series is built for flexible deployment, from small workgroups to distributed data‑center environments.
| Stacking bandwidth | 40 Gbps |
|---|---|
| Maximum PoE+ power per port | 30 W |
| Dimensions (W × D × H) | 440 mm × 325 mm × 44 mm |
| Operating temperature range | 0 °C to 45 °C |
Up to four units can be stacked in a VCStack.
The switches support PoE+ up to 30 W per port.
Each unit provides 40 Gbps of stacking bandwidth.
The devices operate from 0 °C to 45 °C.
