Installation guide for the Agilent 3070 Board Test Systems on MS Windows, covering hardware setup, network configuration, and system verification.
This manual provides step‑by‑step instructions for installing the Agilent 3070 Board Test Systems (MS Windows version). It details required tools, site preparation, hardware assembly, and software configuration, and includes safety cautions for service‑trained engineers.
Key procedures include setting up the KVM and support arms, installing the strip printer and testhead, powering the PDU and controller, configuring network settings, and verifying the vacuum subsystem and testhead operation before handing the system over to the customer.
| Supported GPIB addresses | Defined in section 2‑46 |
|---|---|
| IP address range | 10.3.112.xx series |
| Voltage ranges for DUT power supplies | Specified in section 2‑45 |
Only an Agilent 3070 service‑trained customer engineer (CE) should perform the installation.
Log on as the user "service3070" to complete the installation.
