User manual for the AEG PMSky power automation monitoring system, covering system architecture, software features, technical specifications, and product…
The AEG PMSky Power Automation Monitoring System is an intelligent grid solution designed for real-time monitoring, remote control, and analysis of power equipment. It supports applications in substations, factories, and buildings, ensuring reliable and safe power system operation through advanced communication and computer technologies.
The system features a distributed architecture with a layered network structure (station control, communication, and bay levels). It offers extensive software capabilities including real-time data display, curve analysis, alarm handling, and flexible reporting tools compatible with various database formats. This manual is written in Chinese.
| System Lifespan | ≥ 10 years |
|---|---|
| Mean Time Between Failures (MTBF) | ≥ 30000 hours |
| Telemetry Accuracy | >99.9% |
| Telecommand Correctness | 100% |
| SOE Resolution | 1ms |
| CPU Load (Normal) | ≤ 15% |
The system supports RS232, RS422, RS485 serial ports, as well as Ethernet, GPRS, CDMA, and GSM networks.
The software provides curve analysis including trend curves, X-Y curves, temperature control curves, histograms, and ADO relational database curves.
The system can output reports in Excel, TXT, PDF, HTML, and CSV formats.
