The AEG Full Series Product Manual provides specifications, features, and applications for AEG’s medium‑ and low‑voltage product ranges.
This manual presents AEG’s complete portfolio of medium‑voltage equipment, including the US3.0 gas‑insulated ring main unit, MAST automatic power‑transfer systems, and the SecoVac series of vacuum circuit breakers and contactors. It also covers low‑voltage product families such as MEG and M‑PACT air circuit breakers, Record plastic‑case breakers, and a range of industrial control devices like PFC power‑factor controllers and ASW active power filters.
Technical data sheets, protection ratings, and installation guidelines are provided for each product, with details on rated voltages, currents, IP protection levels, and environmental specifications such as SF6 leakage rates and temperature ranges. This manual is written in Chinese.
| US3.0 rated voltage | 12‑24 kV |
|---|---|
| US3.0 rated current | 630‑1250 A |
| US3.0 IP protection | IP67 (gas box) / IP42 (cabinet) |
| US3.0 SF6 leakage rate | 0.01 % per year |
| SecoVac VL rated voltage | 12‑40.5 kV |
| SecoVac VL rated current | 630‑5000 A |
| MEG air breaker breaking capacity | 50 kA |
The US3.0 unit is rated for 12 kV to 24 kV.
The gas box has an IP67 rating (up to IP68) and the cabinet housing is rated IP42.
The SF6 leakage rate is specified as 0.01 % per year.
