AEG EntelliGuard G air circuit breaker selection manual provides technical data, ratings, dimensions and wiring options for low‑voltage applications.
The manual presents an overview of AEG's low‑voltage product range, focusing on the EntelliGuard G series of air circuit breakers. It includes quick‑selection tables, standard configurations, and a description of the various breaker types and accessories.
Detailed technical data tables list rated currents, voltages, breaking capacities, mechanical and electrical lifetimes, as well as installation dimensions for both fixed and withdrawable units. The document also outlines wiring options, auxiliary contacts, and electronic trip units compatible with the series. This manual is written in Chinese.
| Rated AC voltage (UeVolts) | 690 V / 1000 V |
|---|---|
| Mechanical life (maintained) | 20 000 operations |
