AT10 series automatic transfer switch is a high-performance, intelligent and environmentally friendly product. It adopts a novel transmission mechanism and instant excitation drive technology to ensure the reliability of the product while improving the switching action conversion time.
The AT10 series automatic transfer switches from AEG are designed for reliable power source switching in industrial and commercial settings. The manual covers three controller types – terminal (A‑type), standard (B‑type), and intelligent (C‑type) – and explains their monitoring functions, automatic and manual operation modes, and safety features.
Detailed sections include performance parameters, wiring diagrams, dimensional drawings, and a selection guide with part numbers. The document also lists applicable standards, environmental limits, and technical specifications such as rated current, voltage, and insulation levels. This manual is written in Chinese.
| Rated Working Voltage | AC400 |
|---|---|
| Rated Insulation Voltage | 800 V |
| Rated Working Current Options | 16 A, 32 A, 63 A, 100 A, 125 A, 160 A, 200 A, 250 A, 320 A, 400 A |
| Operating Temperature Range | -5 °C to +40 °C |
| Rated Frequency | 50 Hz / 60 Hz |
| Usage Category | AC‑33A / AC‑33B |
The AT10 is rated for a working voltage of AC 400 V.
The AT10 can operate in ambient temperatures from –5 °C up to +40 °C.
