AEG Full Product Line Catalog

About this manual

This catalog covers AEG’s complete range of medium‑voltage (US3.0 gas‑insulated switchgear, MAST automatic power conversion systems, SecoVac vacuum circuit breakers) and low‑voltage products (MEG and M‑PACT air circuit breakers, Record CPlus molded case breakers). Each product series is described with technical parameters, key features, and typical application fields.

Technical data include rated voltages, breaking capacities, current ratings, and protection classes. The document also lists mechanical lifetimes, environmental ratings, and installation dimensions, helping engineers select the right equipment for power distribution, industrial automation, and infrastructure projects. This manual is written in Chinese.

What's inside

• Medium‑Voltage Product Series
• Low‑Voltage Product Series
• Industrial Control Product Series
• US3.0 Gas‑Insulated Switchgear
• MAST Automatic Power Conversion System
• SecoVac Vacuum Circuit Breakers
• MEG Air Circuit Breakers
• M‑PACT Air Circuit Breakers
• Record CPlus Molded Case Breakers
• PFC Power Factor Controllers

Specifications

Frequently asked questions

What is the rated voltage of the US3.0 gas‑insulated switchgear?

The US3.0 switchgear is rated for 12 kV to 24 kV.

What breaking current can the US3.0 switchgear handle?

It can interrupt currents of 20 kA to 25 kA.

What protection class does the US3.0 gas box have?

The gas‑filled enclosure meets IP67 protection.

What is the rated current range for the US3.0 series?

The series is available with rated currents of 630 A and 1250 A.
