User manual for ABB low‑voltage digital expansion modules covering digital, analog, leakage‑protection, hotspot, wireless temperature modules and sensors.
This manual provides technical function descriptions, installation, configuration and usage instructions for ABB low‑voltage system digital solution expansion modules. It covers digital I/O modules (MB550/MB551), analog I/O module (MA552), leakage‑protection relay (MR580), hotspot monitoring (MT561), wireless temperature module (MT564) and wireless temperature sensor (WT01).
The document includes safety symbols, terminology, wiring diagrams, parameter settings through the main controller (MC510/FC61x/FC710), and a detailed technical‑parameter appendix for each module. This manual is written in Chinese.
| MB550 digital input channels | 4 |
|---|---|
| MB551 digital input channels | 4 |
| MB550/MB551 rated working voltage | 24 V DC or 110 V DC (output), 110 V AC or 240 V AC (output) |
| MB550 power consumption | 0.5 W |
| MA552 analog input type | 0 … 10 V DC |
| MA552 PT100 temperature measurement range | -50 °C … 500 °C |
| MR580 rated working current | 2 A @ 24 V DC (or 0.1 A @ 110 V DC, 4 A @ 120 VAC, 2 A @ 240 VAC) |
| WT01 temperature measurement range | -10 °C … 150 °C |
| Module mounting dimensions (MB550/MB551) | 35.1 mm × 98 mm × 67.5 mm (W × H × D) |
The MB550 module provides four digital inputs.
The modules measure 35.1 mm × 98 mm × 67.5 mm (width × height × depth).
The WT01 sensor can measure temperatures from –10 °C to 150 °C.
