ABB ACS800 Series Inverter PROFIBUS-DP Control Method

About this manual

The note describes the setup of a PROFIBUS‑DP controller (such as a PLC or DCS) for communicating with an ABB ACS800 inverter. It covers installing the ABB GSD file, adding the ABB Drives RPBA‑01 slave, setting the station number, and configuring the data structures for input and output.

It then details the required parameter changes on the inverter, such as setting the operation mode to Vendor Specific, configuring PPO type and PZD channels, and using the control word CW to start, stop, and initialize the motor. A scaling method for fieldbus reference values is also provided. This manual is written in Chinese.

What's inside

• PROFIBUS‑DP Controller Setup
• ACS800 Inverter Parameter Settings
• Control Word CW Motor Start/Stop Method
• Fieldbus Reference Value Scaling
• Conclusion
