SITRANS VP300 intelligent electric valve positioner is used for the position control of pneumatic linear or rotary actuators. It supports plain text and multiple languages, and features non-contact position sensor, OPOS interface, etc.
The SITRANS VP300 is a smart electric valve positioner for pneumatic single‑acting or double‑acting actuators. It supports 4–20 mA input, optional HART communication, and features a non‑contact GMR position sensor, OPOS interface, and extensive diagnostic functions.
The manual covers product description, installation kits, wiring diagrams, operating modes, safety certifications (Ex ia/Ex n, SIL 2), and detailed technical specifications such as travel range, temperature limits, and IP rating. This manual is written in Chinese.
| Travel range (linear actuator) | 3 ~ 60 mm |
|---|---|
| Travel range (angular actuator) | 30 ~ 120° |
| Operating temperature range | -40 °C to +85 °C |
| Ingress protection | IP66 |
| Input signal range | 4 ~ 20 mA |
The VP300 accepts a 4 – 20 mA analog input signal.
The VP300 has an IP66 protection rating.
