TEH1026G is a gigabit Ethernet switch product that provides 24 10/100Mbps adaptive RJ 45 ports, 2 10/100/1000Mbps adaptive Gigabit RJ 45 ports, all ports support parallel/cross cable Automatic identification function, can be used as a normal port or as an Uplink port to cascade to the backbone network.
This manual describes the TEH1026G switch, a 24‑port 10/100Mbps device with two additional 10/100/1000Mbps uplink ports. It covers hardware layout, indicator lights, and key features such as auto‑MDI/MDIX, flow control, and a 4K MAC address table.
Installation instructions, wiring diagrams, and detailed port specifications are provided, along with power requirements, operating conditions, and troubleshooting guidance for indicator LEDs and link status. This manual is written in Japanese.
| Ports (10/100Mbps) | 24 RJ45 |
|---|---|
| Power Input | AC 100‑240V 50/60Hz |
| Maximum Power Consumption | 14 W |
| Operating Temperature | 0 °C – 45 °C |
| Storage Temperature | -30 °C – 60 °C |
| Humidity Range | 59 % – 95 % |
| MAC Address Table Size | 4 K entries |
The switch provides POWER, 100M, 1000M, and LINK/ACT LEDs.
Yes, the switch conforms to EIA rack dimensions and can be installed in a 19‑inch rack using the supplied L‑shaped brackets.
