This document introduces the products of Shenzhen Jixiangtengda Technology Co., Ltd., a registered trademark, including the inventory list, front and rear panel instructions, indicator light instructions, and installation methods. The product is a rack-mounted full-gigabit Ethernet switch with 8/16/24 10/100/1000Mbps adaptive RJ45 ports and supports parallel/cross-twisted pair automatic identification. By using this product, it can solve the bottleneck of data transmission in internet cafes or enterprise networks and improve the transmission rate.
The TEG1008S, TEG1016S, and TEG1024S are rack‑mountable gigabit Ethernet switches offering 8, 16, or 24 RJ45 ports with 10/100/1000 Mbps support. They include auto‑MDI/MDIX, flow control, and LED status indicators for power, link, and speed.
The manual covers front and rear panel descriptions, LED meanings, technical specifications, installation steps, wiring diagrams, and safety precautions. It also provides RJ‑45 pinout tables and troubleshooting tips for proper operation. This manual is written in Chinese.
| Port count | 8 / 16 / 24 ports |
|---|---|
| Supported speeds | 10/100/1000 Mbps |
| Power consumption (TEG1008S) | Maximum 12 W |
| Power consumption (TEG1016S) | Maximum 25 W |
| Power consumption (TEG1024S) | Maximum 30 W |
| Operating temperature | 0 °C – 45 °C |
| Storage temperature | -30 °C – 60 °C |
| Input voltage | AC 100‑240 V, 50/60 Hz |
| MAC address table size | 8 K entries |
The TEG1008S has 8 ports, the TEG1016S has 16 ports, and the TEG1024S has 24 ports.
Each switch includes Power, 1000M, optional 100M, and LinkAct LEDs to show status and link speed.
TEG1008S consumes up to 12 W, TEG1016S up to 25 W, and TEG1024S up to 30 W.
The switches operate from 0 °C to 45 °C.
