This document is an instruction manual for on-site instrument installation and product manuals, which introduces the installation brackets, measurement devices, etc.
This manual provides detailed instructions for installing, commissioning, and operating the Siemens 2900MW high‑voltage generator set. It includes safety guidelines, wiring diagrams, and maintenance procedures.
The document is organized into sections covering system specifications, installation steps, operational controls, and troubleshooting. It also lists component references such as AR444‑220 and AR445‑220 for service technicians. This manual is written in Chinese.
| Power rating | 2900 MW |
|---|---|
| Configuration | 2×900 MW |
The generator set is rated at 2900 MW.
The manual was prepared by Josef Braun and Holger Herrmann.
