This document provides instructions for using SIMATIC 500/505 for configuration, debugging, parameters, optimization, allowed data types, analog alarms, process cycles, and special functions
The manual describes the SIMATIC 500/505 programmable logic controller, covering its hardware interfaces, configuration parameters, and special functions. It explains how to connect the unit via RS232 or RS422 ports and how to set up data areas for program exchange.
Key sections include interface allocation, CPU compatibility, supported Windows operating systems, and detailed steps for programming using STEP 7. The document also lists special functions and limitations for certain CPU models and data areas. This manual is written in Chinese.
| Supported CPUs | CPU 560-2120 and CPU 560-2820 series |
|---|
Compatible CPUs include the CPU 560-2120 and CPU 560-2820 series.
Yes, programming can be done with STEP 7, though ProTool integration has been cancelled.
