This manual provides an introduction to the features and characteristics of the XENYX 502/802/1002/1202 mixers, including safety instructions, operating elements and interfaces, installation, and more.
This manual introduces the XENYX series mixing consoles, covering safety warnings, power connection, and basic handling. It explains each control element, input and output connectors, and the signal flow for both mono and stereo channels.
The document also includes installation guidance, power requirements, and a full technical data sheet with specifications such as frequency response, gain ranges, impedance, dimensions, and power consumption for each model in the series. This manual is written in Chinese.
| Mic input frequency response | <10 Hz – 150 kHz –1 dB |
|---|---|
| Mic preamp gain range | +10 dB to +60 dB |
| Maximum mic input level | +12 dBu @ +10 dB gain |
| Line input impedance | ≈20 kΩ |
| Power consumption (502/802/1002) | 13 W |
| Dimensions (502 model) | 47 mm × 37 mm × 134 mm |
Use only the supplied AC adapter, connect the adapter to the mains first, then connect the mixer to the adapter, and always keep the unit grounded.
The phantom power supplies +48 V and is available on the 802, 1002, and 1202 models.
Set the channel LEVEL knob to the middle (0 dB) and adjust the TRIM knob so the input gain is also 0 dB before recording.
