EUROLIVE E1220A/E1520A are solid, powerful PA speakers with the power and ruggedness of the EUROLIVE Series that have become a favorite of DJs and musicians alike.
This manual describes the installation, wiring and operation of the EUROLIVE E1220A/E1520A power amplifiers. It includes safety cautions, input and output connector descriptions, and guidelines for proper mounting and ventilation.
Technical data such as power rating, THD, frequency response, voltage requirements, dimensions and weight are listed, along with recommended usage notes and troubleshooting tips.
| Power Output (per channel) | 400 W |
|---|---|
| Total Harmonic Distortion (THD) | ≤1 % RMS |
| Input Voltage | 100‑120 V, 50/60 Hz (US) / 220‑230 V, 50/60 Hz (EU) |
| Frequency Response | 60 Hz – 20 kHz |
| Dimensions (W × H × D) | 400 mm × 410 mm × 585 mm |
| Output Level Range | -40 dB to +4 dBu |
Each channel delivers 400 W of power.
It can be powered from 100‑120 V or 220‑230 V at 50/60 Hz.
The amplifier covers 60 Hz to 20 kHz.
Total harmonic distortion is rated at 1 % RMS or less.
