The HTS9800W Cineos home theater system features a neodymium‑metal ribbon tweeter, 6.1 Dolby Digital EX surround sound, HDMI video output with up‑to‑1080i resolution, and wireless rear speakers for a clutter‑free setup. It supports multiple audio formats including Dolby Digital EX, DTS, and Dolby Prologic II, and offers a range of video inputs and outputs.
The manual includes detailed specifications such as power output (3 × 125 W front, 2 × 85 W rear, 105 W rear center, 150 W subwoofer), total RMS power 800 W, frequency response 30‑50000 Hz, and supported on‑screen display languages (English, Portuguese‑Brazil, Spanish, Traditional Chinese, Malay, Canadian French). It also lists accessories, safety information, and wiring diagrams for proper installation. This manual is written in Chinese.
| Audio System | 6.1 Dolby Digital EX, DTS, Dolby Prologic II |
|---|---|
| HDMI Output | Digital video and audio up to 1080i |
| Aspect Ratio | 4:3, 16:9 |
| RMS Output Power | 3 × 125 W front, 2 × 85 W rear, 105 W rear center, 150 W subwoofer |
| Total RMS Power | 800 W |
| Power Supply | 110‑240 V, 50/60 Hz |
| On‑Screen Display Languages | English, Portuguese (Brazil), Spanish, Traditional Chinese, Malay, Canadian French |
It supports 6.1 Dolby Digital EX, DTS, Dolby Prologic II, and standard stereo playback.
Use the HDMI output for digital video and audio up to 1080i, and you can also use analog audio inputs, CVBS, and other connectors listed under other connections.
The standby power consumption is less than 1 W, and the normal operating power consumption is 165 W.
The on‑screen display can be shown in English, Portuguese (Brazil), Spanish, Traditional Chinese, Malay, and Canadian French.
