The HIOKI 8860‑50 and 8861‑50 storage recorders provide high‑speed waveform acquisition up to 20 MS/s with up to 32 high‑speed channels and 128 low‑speed channels. They include REC&MEM functions for simultaneous real‑time recording and memory storage, a high‑resolution LCD, USB‑2.0 and LAN interfaces, and optional external probe modules.
The manual describes system setup, channel configuration, data acquisition, FFT analysis, and data export to PC. It also details the specifications of the built‑in memory, sampling rates, channel counts, and supported accessories such as probe units and printing modules. This manual is written in Japanese.
| Maximum sampling rate | 20 MS/s |
|---|---|
| High‑speed channels | Up to 32 channels |
| Low‑speed channels | Up to 128 channels |
| Resolution | 16 bit |
| USB interface | USB 2.0 |
| LAN interface | Ethernet (LAN) |
| Memory capacity | Up to 1024 kB (per channel) |
The recorder can sample at up to 20 MS/s.
It supports up to 32 high‑speed channels.
Yes, it includes FFT analysis for up to 16 channels.
