This document is a user manual for the DCM230 Docking Entertainment System, providing information on how to use the product and its features.
This manual guides users through the installation and operation of the Philips DCM230 car entertainment system. It includes safety instructions, connection diagrams, remote‑control setup, and detailed button functions for CD/MP3/USB, radio and iPod docking.
Technical specifications, maintenance tips, troubleshooting checklists and compliance information are also provided, helping owners keep the unit running safely and efficiently.
| Power Output | 2 × 15 W RMS |
|---|---|
| Signal‑to‑Noise Ratio | ≥ 70 dBA |
| Frequency Response (Audio) | 20 Hz – 20 kHz ± 3 dB |
| AUX Input Sensitivity | 0.5 V (max 2 V) |
| Headphone Impedance | 4 Ω |
| Speaker Impedance | 32 Ω |
| FM Tuner Range | 87.5 – 108 MHz |
| Dimensions (W × H × D) | 390 × 140.5 × 200.5 mm |
| Weight | 2.33 kg |
| Power Consumption (Normal) | < 7 W |
| Power Consumption (Eco Standby) | < 1 W |
