This is a user manual for the DN-X1700 digital mixer, which introduces the basic functions, connection methods and operation methods of the mixer.
This manual provides safety instructions, handling precautions, and detailed descriptions of the DN‑X1700’s main features, including high‑resolution audio, multiple inputs, and USB/MIDI interfaces. It also covers installation guidelines, cleaning, and recommended maintenance practices.
The later sections guide users through troubleshooting, warranty information, and service procedures, with step‑by‑step instructions for adjusting cross‑fader torque, enabling start functions, and configuring USB audio settings. This manual is written in Japanese.
| Audio resolution | 96kHz/32bit DAC |
|---|---|
| Mic preamp EIN | 127dB |
| PHONO amp S/N ratio | 89dB |
| Inputs | 4 CD/PHONO, 4 digital, 2 mic |
| USB audio | 8‑channel (4 stereo) 96kHz |
Check the troubleshooting table in the manual, verify the power cable and connections, and contact the dealer or service center if the problem persists.
Turn the FLEX FADER torque adjustment knob to set the desired cross‑fader resistance.
