SIMOREG DC-MASTER is an excellent DC drive system with features including comfort, reliability, cost-effectiveness, efficiency, and intelligence. The new generation of SIMOREG DC-MASTER offers the best solutions for challenging drive applications and standard solutions. It has fast control characteristics with a rise time of less than 10ms and a wide output power range. The system can be integrated into any automation environment and provides continuous monitoring, accurate diagnostics, and efficient maintenance and service. It is suitable for various industrial applications and provides the highest performance and intelligence.
This manual introduces the SIMOREG DC‑MASTER family, highlighting its fast control characteristics, wide output power (6 kW‑1900 kW) and voltage (400‑830 V) ranges, and modular design for integration into any automation environment. It also details the compact Siemens DC motor options, protection ratings, and the system’s high‑intelligence communication capabilities.
Technical data, selection tables, and a comprehensive list of optional accessories are provided, along with service principles, quality guarantees, and worldwide support contacts. The document includes instructions for parameter reading/writing via OP1S, RS‑485 device‑to‑device communication, and integration with PROFIBUS‑DP. This manual is written in Chinese.
| Maximum output current | 12,000 A |
|---|---|
| Input voltage range | 400 V – 830 V |
| Output power range | 6 kW – 1900 kW |
| Current rise time | < 10 ms |
The system can deliver up to 12,000 A of output current.
It operates with an input voltage from 400 V to 830 V.
The output power ranges from 6 kW to 1900 kW.
