The Ruckus ICX 7250 Switch specifications detail port options, PoE budgets, routing features, dimensions and compliance information.
The ICX 7250 series provides flexible Ethernet access with 24 or 48 RJ‑45 ports, optional PoE/PoE+ support, and up to four 10 GbE SFP+ uplinks. It includes advanced L3 routing protocols such as RIP, OSPF, VRRP, PIM and PBR, and supports Campus Fabric for scalable deployments.
Physical specifications include a 1U rack‑mount design (440 mm × 280 mm × 437 mm for the 24‑port model), operating temperatures from –5 °C to 50 °C, and compliance with FCC, EN, and RoHS standards. Power over Ethernet budgets reach 370 W for PoE models and each PoE+ port can deliver up to 54 W.
| Forwarding rate | 190 Mpps |
|---|---|
| Maximum PoE power budget (24P model) | 370 W |
| Maximum VLANs | 4096 |
| Maximum MAC addresses | 16,384 |
The ICX 7250‑24P model provides a PoE power budget of 370 W.
Supported routing protocols include RIP, OSPF, VRRP, PIM and PBR.
The device operates from –5 °C to 50 °C.
