This document provides information on the mounting location and wiring diagrams of RDF310 and RDF410 Building Technologies/HVAC products. It also includes dimensions for semi-flush-mounting and descriptions of related components.
This manual provides the required information to install the Siemens RDF310 and RDF410 thermostats. It includes the recommended semi‑flush mounting location, reference numbers for the mounting area, and basic layout guidelines.
The document also contains wiring diagrams (reference #2224) showing the electrical connections for each model, along with the applicable ratings such as 10 A current and 230 V AC supply. Dimensional drawings give the overall size of the units for proper fitting.
| Maximum current | 10 A |
|---|---|
| Supply voltage | AC 230 V |
The thermostat should be installed in a semi‑flush mounting position as shown in section #223 24 B.
The thermostat operates on an AC 230 V supply.
