DocuPrint 202 is a new generation A3 laser printer with features such as high-speed printing, duplex printing, and high resolution.
This manual covers the DocuPrint 202 A3 laser printer, detailing its specifications, optional accessories, consumables, and operating environment. It includes information on print speeds, paper handling, supported media, power consumption, and noise levels.
The document also explains network printing setup, supported software platforms, and service options such as on‑site maintenance. Contact information for Fuji Xerox branches across China is provided for support and service inquiries. This manual is written in Chinese.
| Single‑sided print speed (A4) | 20 pages per minute |
|---|---|
| Single‑sided print speed (A3) | 11 pages per minute |
| Duplex print speed (A4) | 13 pages per minute |
| Duplex print speed (A3) | 8 pages per minute |
| Maximum monthly print volume | 65,000 pages |
| Supported media sizes | A3, B4, A4, B5, A5, Letter, Legal, up to 900 mm length |
| Resolution | 600 dpi |
| Interface | Parallel port / USB 1.1 |
| Dimensions (W×H×D) | 505 mm × 324 mm × 376 mm |
| Weight | 19.5 kg |
| Power consumption | 15 W (sleep), 25 W (standby), 360 W (average), 955 W (max) |
| Noise (operating) | 52 dB |
| Noise (standby) | 24 dB |
The printer can handle up to 65,000 pages per month.
It prints A4 pages at a rate of 20 pages per minute in single‑sided mode.
The printer uses 15 W in sleep, 25 W in standby, 360 W on average, and up to 955 W at maximum load.
It provides a bidirectional parallel port and a USB 1.1 interface.
