Phaser 3117 is a simple and stylish desktop laser printer with a printing speed of 17ppm(letter)/16ppm(A4) and a first-page output time of 10 seconds or less. It supports USB 1.1(compatible with USB2.0) interface.
The Phaser 3117 is a compact desktop laser printer designed for fast, high‑quality monochrome printing. It supports a variety of paper sizes and includes special functions such as eco‑mode, scaling, N‑in‑1 and watermark printing.
This manual contains the printer’s technical specifications, instructions for installing and configuring the device, guidance on replacing consumables, and details on network and software compatibility. It also explains the anti‑counterfeit features of the consumables and provides safety and environmental information. This manual is written in Chinese.
| Print speed | 17 ppm (letter) / 16 ppm (A4) |
|---|---|
| Processor | 150 MHz |
| Print resolution | 600 × 600 dpi |
| Interface | USB 1.1 (compatible with USB 2.0) |
| Paper output capacity | 50 pages |
| Dimensions (W × D × H) | 354 mm × 297.4 mm × 210 mm |
| Operating temperature | 10 °C – 32 °C |
| Operating humidity | 20 % RH – 80 % RH |
| Noise level (standby / printing) | < 30 dB / < 50 dB |
| Power consumption (printing / sleep) | 300 W / 10 W |
| Toner drum part number | 106R01159 |
The printer can output 17 pages per minute for letter size and 16 pages per minute for A4 size.
It uses a USB 1.1 interface that is compatible with USB 2.0.
The device operates between 10 °C and 32 °C and 20 % RH to 80 % RH.
The toner drum part number is 106R01159, as listed in the consumables section.
