This document introduces the specifications and features of the TC-20LA5G GLP2N LCD TV, which is copyrighted by Shandong Panasonic Electronic Information Co., Ltd. The TV uses AC 220-240V power supply with an average power consumption of 77W. It has a 50cm LCD screen with a 4:3 aspect ratio. The sound features two 9cm×5cm speakers with a total audio output of 6W. The TV supports various receiving channels and cable TV. The connection terminals include AV1, AV2, S-VIDEO, AUDIO L-R, etc. The overall dimensions are 498mm×506mm×260mm, and the weight is 8kg.
This manual covers safety precautions, environmental limits, and the technical specifications of the TC-20LA5G LCD television, including power requirements, screen size, audio output and connector layouts. It also lists the supported video standards and provides wiring diagrams for AV, S‑Video and audio connections.
Detailed repair procedures are described, such as how to open the chassis, replace components, perform self‑test functions, and handle electro‑static discharge protection. A complete parts list with reference numbers and a troubleshooting guide help technicians diagnose and fix common faults. This manual is written in Japanese.
| Input voltage | 220‑240 V, 50/60 Hz |
|---|---|
| Standby power consumption | 0.5 W |
The standby power consumption is 0.5 W.
The TV supports PAL B/G/H, PAL I, PAL D/K, SECAM B/G, SECAM D/K, NTSC variants and others listed in the manual.
