This document provides information on the range, accuracy, and model of the four-channel thermocouple temperature module and the differential pressure and temperature module. It also includes detailed descriptions of the differential pressure input port and the thermocouple temperature input port, as well as a list of measurement instruments compatible with the measurement module.
This document provides technical data sheets for a range of intelligent measurement modules manufactured by KIMO. The listed models include the MDP series (four-channel thermocouple and differential pressure), MCT (dual-channel current/voltage), and MHT/T63 (humidity, temperature, and atmospheric pressure). This manual is written in Chinese.
| Thermocouple Range (K Type) | -200 ~ +1300 °C |
|---|---|
| Thermocouple Accuracy | ±1.1 °C or ±0.4% of reading |
| Differential Pressure Range (MDP 500) | -500 ~ +500 Pa |
| Differential Pressure Accuracy (MDP 500) | ±0.2% of reading ±0.8 Pa (-100~+100 Pa) |
The modules are suitable for MP 200, AMI 300, VT 200, HD 200, TM 200, AQ 200, and AMI 300 instruments.
The response time is 50 seconds at an air flow velocity of 2 m/s.
It uses a piezoresistive sensor for pressure, capacitive for humidity, and semiconductor for temperature.
