The KIMO DB100 is a sound level meter featuring a prepolarised electret condenser microphone with a nominal sensitivity of 20 mV/Pa. It complies with IEC 61672-1 Class 2, IEC 61651 Class 2, and IEC 60804 Class 2 standards. The device measures sound pressure levels (LA) and time-averaged levels (LAeq) with A-weighting and selectable fast or slow time weighting.
| Microphone type | prepolarised electret condenser |
|---|---|
| Nominal sensitivity | 20 mV/Pa |
| Standards | IEC 61672-1 Class 2 / IEC 61651 Class 2 / IEC 60804 Class 2 |
| Measured parameters | LA and LAeq |
| Frequency weighting | A |
| Measuring range | 30-130 dB |
| Time weighting | slow, fast |
| Data integration time for LAeq | from 1s to 15 min |
| Display resolution | 0,1 dB |
| Reference frequency | 1000 Hz |
| Operating temperature | from -10 °C to + 50 °C |
| Battery life (min) | 30 hours |
| Power supply | 3 AAA or rechargeable batteries |
It complies with IEC 61672-1 Class 2, IEC 61651 Class 2, and IEC 60804 Class 2.
The measuring range is from 30 to 130 dB.
Yes, it can measure time-averaged or equivalent continuous sound pressure level (LAeq).
The battery life is a minimum of 30 hours at 20°C when using alkaline batteries.
