A product catalog listing specifications, models, prices, and technical details for KIMO pressure transmitters, manostats, humidity sensors, and accessories.
This document is a price list and specification guide for KIMO's range of pressure measurement instruments. It covers Class 50 through Class 300 differential pressure transmitters (models CP series), manostats (PST series), and barometric pressure transmitters.
The catalog details various configurations including flush-mount units, wall-mounted housings, and atmospheric sensors. Technical specifications provided include configurable measurement ranges from -100 to +100 Pa up to -10,000/+10,000 Pa, output types (4-20 mA, 0-10 V), power supply requirements, housing materials (ABS, Aluminum, Stainless Steel), and optional accessories like remote controls and configuration software.
| Output Signal (CP50/CP100) | 4-20 mA and 0-10 V |
|---|---|
| Power Supply (CP50/CP100) | 24Vdc/Vac |
| Housing Protection Class | IP65 |
| Configurable Range (CP300) | -10,000 to +10,000 Pa |
| Relay Configuration (CP300) | 6A/230Vac |
The minimum configurable range is 0 to ±100 mmH2O.
Yes, it features a thermocouple K input for temperature compensation of air velocity and airflow.
