This document introduces the specifications of the HP-200V oil-free miniature vacuum pump, including rated voltage, input power, maximum airflow, maximum vacuum degree, noise, and operating temperature.
The document is a single-page specification sheet for the HP HP-200V oil-free miniature vacuum pump. It details key operational parameters such as rated voltage (220V/50Hz), input power (50W), maximum air flow rate (200 L/min), and maximum vacuum degree (-92 KPa). This manual is written in Chinese.
| Rated Voltage/Frequency | 220V/50Hz |
|---|---|
| Input Power | 50W |
| Maximum Air Flow Rate | 200 L/min (12 m3/h) |
| Maximum Vacuum Degree | -92 KPa (-700 mmHg) |
| Noise Level | 60 dB(A) |
| Operating Temperature Range | 5-40 C |
| Cold Insulation Resistance | >100 MO (at 20C) |
| Dielectric Strength | 1500V/50Hz 1min |
| Thermal Protector Cut-off Temp | 130+5 C |
| Installation Dimensions (L*W) | 203*112mm |
| Overall Dimensions (L*W*H) | 244*128*205mm |
| Inlet/Outlet Thread Specification | 378-18PT |
The maximum airflow is 200 L/min.
The maximum vacuum rating is -92 KPa.
The operating temperature range is 5-40 C.
