This document is the warranty terms and disclaimer for Behringer products
The guide begins with safety warnings and installation notes, stressing that only qualified personnel should perform adjustments, that the unit must stay away from water, liquids and heat sources, and that the cabinet should never be opened by the user.
It then explains how to connect the monitor to a mixing console or computer using XLR, TRS or RCA inputs, how to power the unit, set the INPUT TRIM, and start playback. Technical specifications such as input types, impedance, frequency response, SPL rating and power consumption are listed, followed by warranty and registration information. This manual is written in Chinese.
| Input connectors | XLR balanced, TRS balanced, RCA unbalanced |
|---|---|
| Input impedance | 10 kΩ |
| Input trim range | -6 dB to +6 dB |
| Maximum input level | +22 dBu |
| Frequency response | 50 Hz – 20 kHz |
| Maximum SPL | 110 dB SPL @ 1 m |
| Power consumption | 100‑240 V 50/60 Hz, 100 W |
| Dimensions (H × W × D) | 288 mm × 198 mm × 280 mm |
| Weight | 55 kg |
Only qualified professionals should perform installation or adjustment, keep the unit away from water, liquids and heat sources, and never open the cabinet.
Connect the console’s XLR outputs to the monitor’s XLR balanced inputs, or use the TRS or RCA inputs as shown in the guide.
