Extech 380976 3-phase power clamp meter measures power (W), apparent power (kVA), reactive power (kVAR), horsepower (HP), power factor, and phase angle.
The EXTECH 480172 is a 3-Phase True RMS Power Clamp Meter designed for AC power evaluation, motor/generator installation, and HVAC flame rod tests. It features a large dual LCD display and measures current, insulation resistance, temperature, and various power parameters including True, Apparent, and Reactive Power.
| True Power Range | 6000W |
|---|---|
| AC Current Range | 1000A |
| AC/DC Voltage Range | 600V |
| Temperature Range | -58 to 1000°F |
| Dimensions | 9x 3x 1.6" (228 x 76 x 39mm) |
The meter measures current, insulation resistance, temperature using a Type K probe, and power including true, apparent, and reactive power.
The meter can measure temperatures up to 1000°F using a Type K probe.
